Description

LOA 93.4 m
Beam 19.2 m
Draft 6.82 m

Built in year 2005
Design is : ST-216-L-CD
Class : DNV
Flag : Norway
Gross Tonnage of 4,180 and Nett Tonnage of 1,260

Dynamic Positioning of class : DP 2
Free Deck area about 1,041m² with a deck strength of 10 metric tonnes per square meter
Fire Fighting System installed
1 Crane / Gear installed with a max lifting capacity of 4 tons
1 Crane / Gear installed with a max lifting capacity of 1.5 tons
Deadweight : 5,304 metric tonnes
Ice classed 1C
Capable of supplies of 1,340m³ Fuel Oils, 150m³ Methanol, 1,216m³ FW, 907m³ Liquid Mud and 456m³ Brine

Total passenger capacity 28 with 28 berths
12 cabins with 1 berth
8 cabins with 2 berths

Speed : 13.5 knots
Engines : 2 x Caterpillar / Caterpillar Inc 3612, 7,600 kw, 900 rpm, Propellers 1 Directional (Port Side) + 1 Directional (Starboard)
Auxiliaries Engines : 2 Caterpillar 590 kw, Bowthruster + No Sternthruster (3 Bow Tunnel thruster 770kw)

Specifications

Engine(s)

2 x 7,600 kw, 900 rpm, Caterpillar / Caterpillar Inc 3612,
Propellers: 1 Directional (Port Side) + 1 Directional (Starboard)

Certification

REGISTERED Achilles Member:
- UVDB Registered
- CONNEXIO Accredited
- SELLIHCA Qualified

MEMBER Renewable Energy Hamburg
MEMBER Bundesverband Windenergie
MEMBER Windenergie Agentur Bremerhaven
MEMBER Windenergy Network

Disclaimer

GRS performs its services exclusively on the basis of its General Terms and Conditions, which are available at the GRS website www.grs-offshore.com.
All details are given in good faith but without guarantee. Subject to availability.
